Model - START



The Harwi Helios 60 vertical panel saw is an excellent choice when you
are dealing with an intensive sawing process that requires high accuracy.

The Helios 60 is equipped with a powerfull 4kW electric motor that
indirectly drives the sawing blade up to 5000 rpm.
The strong frame construction and stable sawing beam ensures
the perfect cut.

Due to its maintenance friendly character and long lifespan, interior
builders & carpentry factories have been charmed by our Helios 60
machines for years.

The Harwi Helios 60 is available in a Start, Basic, Premium or Pro version.

Harwi Helios 60
Model Specification - Start

Electrical moving backpanel ✓

Length stop (analoog) ✓

24V DC power supply for dust extractor ✓

Midway fences ✓

Short feet ✓

Reiteration stop ✓

Stop for horizontal cuts ✓

Support midway fence ✓

Midway fence guiding block ✓

TRK Dust extraction horizontal X

Transportrollers foot operated X

Measuring stop analog for vertical cutting X

Measuring stop digital for vertical cutting X

Alu rollers & plate clamp X

Frequentie controller 4.0 kW X

Measuring stop extention X

Horizontal extention 1 meter (155/185/215) or 2 meters (185) X

Digital readout for horizontal cutting X

✓ = Inclusive |  X = Not possible |  O = Option



Harwi Helios 60 Start

-Cutting height horizontal 1250/1550/1850/2150mm

-Cutting height vertical 1300/1600/1900/2200mm

-Cutting length 2500/3300/3300/3300mm

-Cutting depth 60 mm

-Sawblade diameter ø 250 mm

-Sawblade hole ø 30 mm

-Motorpower 4 kW (5.5 HP)

-Voltage 400 Volt / 3N

-Rotation sawblade 5.000 rpm

-Dustextraction daimeters ø 160 mm
