The Fox Range of machines has been designed to suit the small to medium size manufacturer due to its compact footprint and ease of use. Designed for customers looking to make that first big step into the CNC world. The Cosmec Fox 16 CNC offers high performance and a very simple approach to CNC technology. Like all pantographs made in COSMEC TECHNOLOGY, the FOX is equipped with a highly rigid structure in electro-welded steel, a high vacuum depression system and top quality components. It is available in 3 or 4 axis versions, and the latest addition to the range is the 5 axis version for the FOX 22 model. New Cosmec Fox 16 CNC Machine Tech Spec- -Working Area 4140 x 2200 -Maximum Panel Passage Thickness 200mm -Vector Velocity 35m/min. -Linear Speed 24m/min. -Vacuum Pump Capacity 100 m3/h -Spindle Rotation Speed Max. 24,000 rpm -Spindle Power 13Kw -Tool Attachment ISO 30 Optional- - Vector Velocity 85m/min* -Linear Speed 60m/min* -Vaccum Pump Capacity 250 m3/h* -Wheel / Rack Tool Change 12 / 8 Positions* -Spindle Rotation Max. 36,000* rpm or 40,000 rpm* -Tool Attachment HSK F63* / HSK E 40* / HSK E 32* The bridge type construction makes for a solid stable machine which is capable of machining MDF, MFC, Corian, Acrylics and Plastics as well as other materials commonly used. The software included comes complete with the Aspan Nesting option to enable easy nesting of components when required Specialist in CNC machinery. CNC machine produced to your exact specification/needs. **Price on Application** QUALITY, TECHNOLOGY AND RELIABILITY MAXIMUM CUSTOMIZATION AFTER-SALES ASSISTANCE Since 1960 Cosmec Technology, founded in 1960 and now in its third generation, has gained a strong experience in Research and Development in the sector of machines for working wood, plastic, aluminium, composite materials and similar. Known both nationally and internationally for its prestigious Quality, Technology and Reliability, it has managed to bring great innovations to the world market and to have a constant vision towards the future. The current product range includes CNC drilling and milling machines. Thanks to our know-how we are able to customize our products according to customer needs. The company summarizes the results obtained well over 2,500 CNC milling machines operate in the world.
